Flow straightener included: irregular air patterns such as those from swirl outlets are straightened before measurement for more accurate results.
Vane anemometer with measuring funnels and flow straightener
Flow straightener included: irregular air patterns such as those from swirl outlets are straightened before measurement for more accurate results.
Product overview
Testo 417 Kit 2 combines the 100 mm vane anemometer with measuring funnels and a flow straightener. The straightener conditions swirling or uneven airflow before it reaches the vane, which improves accuracy on swirl diffusers and similar outlets.
Key capabilities
testo 417 kit 2
Measuring funnels included: they fit over air outlets directly, so volume flow is not limited by mounting position.
100 mm vane plus app: a 0.3 to 20 m/s range with on-site recording and reporting.
Technical specifications
12 Technical specifications
- Velocity
- 0.3-20 m/s, accuracy +/- (0.1 m/s + 1.5 % of mv)
- Temperature
- 0...+50 C
- volume flow up to
- 99,999 m3/h
- Equipment
- 100 mm vane
- Protection class
- IP10
- Weight
- 243 g
- 3x AA,
- 50 h
- delivery adds measuring funnels and flow straightener (0554
- 4172) for swirl outlets
- Vane diameter
- 100 mm
- Velocity range
- 0.3 to 20 m/s
- Included
- measuring funnels and flow straightener
- Parameters
- air velocity, volume flow, temperature
