Measuring funnels included: the two funnels fit over air outlets directly, so volume flow can be measured regardless of mounting position.
Vane anemometer with measurement funnels
Measuring funnels included: the two funnels fit over air outlets directly, so volume flow can be measured regardless of mounting position.
Product overview
Testo 417 Kit 1 adds measuring funnels to the 100 mm vane anemometer. The funnels sit over the air outlet so volume flow can be captured on grilles and diffusers that are hard to reach with the vane alone.
Key capabilities
testo 417 kit 1
100 mm vane: a 0.3 to 20 m/s range for stable volume flow readings at diffusers.
Velocity, volume flow and temperature in one: data is recorded and reported through the app.
Technical specifications
12 Technical specifications
- Velocity
- 0.3-20 m/s, accuracy +/- (0.1 m/s + 1.5 % of mv)
- Temperature
- 0...+50 C
- volume flow up to
- 99,999 m3/h
- Equipment
- 100 mm vane
- Protection class
- IP10
- Weight
- 243 g
- 3x AA,
- 50 h
- Delivery scope
- delivery adds plate funnel and grille funnel for measuring at ventilation outlets
- Vane diameter
- 100 mm
- Velocity range
- 0.3 to 20 m/s
- Included
- measuring funnels
- Parameters
- air velocity, volume flow, temperature
